Environmental/Materials |
Insulator |
Fibreglass filled thermoplastic UL94VO |
Contacts |
Male: Tin plated copper alloy, hard acid
gold plated |
Female:
|
Gold or tin-plated copper alloy socket
Gold plated berylum copper inner contact
|
Fixing Hardware |
Latch: Beryllium copper alloy socket |
Jackscrew: stainless steel |
Operating Temperature |
from -55°C to + 125°C (IEC 68-1) |
from -67°F to 257°F |
Complies with vapour phase and infrared
techniques |
Vibration severity |
0.75mm, 10 g RMS 6 hours long random with
superimposed sinusoid. No imtermittancies measured when using an H.S.L.I
(High Speed Logic Interrupt) detector with a trip threshold of 2 ns |
Shock severity |
100 g for 6 ms |
Resistance |
HcFc 141 bMGX (ATOCHEM) solvent |
